363-206-285 System Turnup: NTP-003
Issue 2, February 2000 Page 5 of 6
DDM-2000 OC-3 MULTIPLEXER
DO ITEMS BELOW IN ORDER LISTED . . . . .FOR DETAILS, GO TO
11. Make necessary VT1.5/STS1 cross-connections at each node in
the network.
DLP-546A. Single Ring Configuration
DLP-550B. Dual Ring Interworking (DRI) Configuration
DLP-557C. Single/Dual OC-3/FiberReach Configuration
DLP-558D. Stand Alone OC-3/FiberReach Configuration
DLP-559E. Single/Dual OC-3/OC-48 Configuration
DLP-560F. Single/Dual OC-3/OC-12 Configuration
12.
NOTE:
For a DS1 circuit in a path protected ring network, the
sw-path-( ):address commandmustbeusedatthe
terminating nodes [and dual ring interworking (DRI) nodes in
a DRI ring network] to switch the active VT1.5 (DS1) path to
repeat this test on the other path(s).
Perform DS1 end-to-end transmission test for each circuit being
put into service, as required.
DLP-510A. Ring Configuration
DLP-554B. Dual Ring Interworking (DRI) Configuration
DLP-510C. OC-3/FiberReach Configuration
13. Use the rtrv-state-eqpt: command to determine the port
state of the DS1 port(s) of the circuit being established.
14.
NOTE:
If a port is in the nmon (n) state, the signal is not monitored
or alarmed. The port will not automatically go to the in
service (i) state when a signal is detected as it will in the
auto (a)state.Inthenmon state, the port must be returned
to the auto state, using the set-state-t1: command, to
turn on monitoring of signal failures and before any circuit
packs associated with that port can be removed from the
equipment list by the upd command.
Use the set-state-t1: command to set the port state of the
DS1 port(s) of the circuit being established.
15. Use PairGain Technologies procedures to access the faceplate
RS-232 interface and set HDSL link management features for
each port being provisioned.
DLP-546
DLP-550
DLP-557
DLP-558
DLP-559
DLP-560
DLP-510
DLP-554
