MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the Control Unit
Page 2-40
Installing the Modules
Figure 2-12. Line/Trunk and Telephone Jack Locations on Each Module
800 GS/LS
8 GS/LS Outside Lines
PFT Jack
PFT
Line/Trunk
Jacks
Off-Premise
Telephone Jacks on
008 OPT Module
Extension
Telephone
Jacks (Analog or Digital)
8
5
4
1
8
1
*
*
or
