MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-55
Assembling MLX Telephones
Figure 3-37. Mounting the Backplate
d. Attach the backplate to the wall; see the instructions provided with
the 630B Phonemount.
e. Insert the two short screws provided with the Phonemount into the
mounting plate. Be sure to thread the upper screw through the
jack guard. See Figure 3–37.
Jack Plug
Mounting Plate
630B
Phone
Mount
Jack Guard
