Lucent Technologies MERLIN LEGEND Release 6.1 - Changing the Key Mode Switch Position to Closed

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Upgrading the System
Page 9-17
Modifying the Processor for Key Mode
Figure 9-7. Changing the Key Mode Switch Position to Closed
PROCESSOR CIRCUIT BOARD
Rear
Front
2
1
OPEN
KEY
ONLY
PBX
CLOSED
(KEY)
OPEN
(PBX)
2
1
