MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the Control Unit
Page 2-27
Installing the Auxiliary Power Unit
Figure 2-8. Installing an Auxiliary Power Unit
AC
Outlet
-48 VDC
Auxiliary
Power
Input
AC
Input
Auxiliary
Power
Unit
AUX
POWER
AC
INPUT
-48 VDC
Power Cord
Control Unit
AC Power Cord
Ground
Wire
Ferrite
Cores
A
UX Power Unit
A
C Power Cord
Processor
