MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-62
Connecting Telephones to the Control Unit
Figure 3-39. Connecting Two Voice Pairs to a Telephone Using a Bridging
Adapter (BR-241-B1)
Bridging
Adapter
(BR-241-B1)
EVEN #
Station
ODD #
Line
Telephone
Processor
408 408 408 408 408
D8W
Central
Office
Lines
