MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-34
Installing Adjuncts
MERLIN Identifier
MERLIN Identifier allows the use of local telephone company caller
identification services to receive, store, and use calling party number
information. Before installation, verify that this service provided by the
central office is available on the lines to be connected. Each MERLIN
Identifier consists of the following:
â–  A control unit, which must be located near the MERLIN LEGEND
control unit
â–  Up to four individual display units, which can be mounted on
analog multiline telephones or wall-mounted for both analog and
MLX telephones
â–  An administrative keyboard
Optional equipment includes an administrative display, a PC, and a
serial printer.
For detailed instructions, see
MERLIN Identifier Installation and
Administration.
When MERLIN Identifier is used with MLX telephones, a pair of
installer-wired 104A termination outlets is required for each MLX set that
is connected to a MERLIN Identifier display unit.
Modems
You can connect a modem to one of the following:
â–  Single-line telephone
â–  MLX telephone with an MFM
â–  GPA and analog multiline telephone
NOTE:
When a modem is connected to the TEL/OTHER jack on the MLX
telephone equipped with an MFM, data calls can be made from the
