MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Connecting Data Equipment
Page 6-9
Modem Data-Only Stations
Figure 6-2. Modem Data-Only Equipment Configuration
Processor
TURN OFF
POWER BEFORE
INSERTING OR
REMOVING
MODULES
CAUTION
012 Module
Modem
LINE jack
D4BU
cord
SERIAL
connector
EIA-232-D Cable
Tip Ring
Extension
jack
008 OPT Module
AC Outlet
AC Outlet
