Lucent Technologies MERLIN LEGEND Release 6.1 Installation

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-2
Connecting a PC to the Control Unit
Connecting a PC Within 50 Feet
Use this procedure to connect a PC to the control unit when the PC is
within 50 ft. (15.2 m) of the control unit.
You need the following hardware for this procedure:
■ 355AF adapter
■ D8W cord
■ EIA-232-D cable (optional)
To connect a PC within 50 ft. (15.2 m) of the control unit, follow the steps
below. See Figure 5–1.
!Connect the D8W cord.
■ For system programming or maintenance, plug one end of a D8W
cord into the ADMIN jack on the control unit.
■ For SMDR, plug one end of a D8W cord into the SMDR jack on
the control unit.
!Plug the other end of the D8W cord into a 355AF adapter.
!Connect the 355AF adapter.
■ If you are using an EIA-232-D cable, plug one end of the cable
into the 355AF adapter and plug the other end into the COM1 port
on the PC.
■ If you are not using an EIA-232-D cable, plug the 355AF adapter
directly into the COM1 port on the PC.
