Lucent Technologies MERLIN LEGEND Release 6.1 Installation

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-24
Connecting a Printer to the Control Unit
* Open= off; Closed = on
Table 5-2. Lucent Technologies 475/476 Printer DIP Switch Settings
*
Switch 1 Switch 2 Switch 21
DIP 1-Open DIP 1-Open DIP 1-Open
DIP 2-Closed DIP 2-Open DIP 2-Open
DIP 3-Open DIP 3-Open DIP 3-Open
DIP 4-Open DIP 4-Open DIP 4-Closed
DIP 5-Closed DIP 5-Open DIP 5-Open
DIP 6-Closed DIP 6-Open DIP 6-Open
DIP 7-Closed DIP 7-Closed DIP 7-Open
DIP 8-Open DIP 8-Open DIP 8-Closed
Switch 22 Switch 23 Switch 24
DIP 1-Open DIP 1-Closed DIP 1-Open
DIP 2-Closed DIP 2-Open DIP 2-Closed
DIP 3-Closed DIP 3-Open DIP 3-Closed
DIP 4-Open DIP 4-Open DIP 4-Open
DIP 5-Closed DIP 5-Open
DIP 6-Open DIP 6-Closed
DIP 7-Open
DIP 8-Closed
