MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-22
Installing Adjuncts
c. Plug the power supply into a 117-V AC outlet that is not controlled
by a wall switch.
d. Insert the plug end of the 400B or 400B2 adapter into the wall
jack.
! Test the MFM for T/R operation.
See “Testing MLX Telephones with MFMs” in Chapter 7.
! Attach the adjunct to the MFM. See “Installing Adjuncts.”
Installing Adjuncts
This section provides general instructions for connecting most adjuncts.
NOTE:
If you need to connect the adjuncts differently from the instructions
on the system forms, record each jack and adjunct change on the
appropriate system numbering form. See Appendix A, “System
Numbering Forms.”
!Connect one end of the cord packaged with the adjunct (usually a
D4BU cord) to the adjunct.
See the documentation packaged with the adjunct for instructions.
!Check the system form for the adjunct you want to connect. Then
refer to the appropriate step below.
■ To connect an adjunct to an MLX telephone, go to Step 3.
■ To connect an adjunct to a single-line telephone, go to Step 4.
■ To connect an adjunct to an analog multiline telephone, go to
Step 5.
■ To connect an adjunct to a 012 or 016 (T/R) module, go to Step 6.
When you connect adjuncts to telephones, make sure you route the
adjunct and D8W telephone cords through the cord channel. See Figure
3–20.
