MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-19
Installing Multi-Function Modules
Figure 3-17. Replacing the User Card Tray and Line Cable
! Replace the user card tray and line cable. See Figure 3–17.
a. Insert the user card tray at an angle, then lower and slide into the
deskstand.
b. Replace the line cable into the line jack in the deskstand.
STAND ADJUSTMENT
2
1
4
3
P
R
E
S
S
&
L
I
F
T
L
O
W
H
I
G
H
Line
Cable
Card
Tray
Deskstand
Telephone
Base
