MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing Telephones and Adjuncts
Page 3-13
Installing Multi-Function Modules
Figure 3-11. Removing the Jack Guard
!To remove the jack guard, see Figure 3–11.
a. If the module cover has a square jack guard that protects the
TEL/OTHER jack area, grasp and twist the guard to remove it.
Save the jack guard if you are wall-mounting an MLX-5, MLX-5D,
MLX-10, MLX-10D, or MLX-16DP telephone.
MFM Jack Guard Cover
T
E
L
/O
T
H
E
R
TEL/OTHER
