MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Connecting the Control Unit to the Network Interface
Page 4-8
Wiring
Figure 4-3. RJ21X Wiring Field Tools
To connect the RJ21X network interface to the control unit, follow the
steps below. Figure 4–3 shows the tools you need.
!For each piece of hardware, drill two diagonally opposite holes into
the backboard, allowing for a 1/16-inch (1.6 mm) space between
each piece of hardware.
!Mount the wire troughs and the termination blocks.
There is a wire trough above and below each termination block.
AT-8762 D
Impact Tool
Spudger
788 K1 Retainer
Tool
110 Impact Tool
788J1
Modular Plug Pressers
