MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Connecting the Control Unit to the Network Interface
Page 4-21
Wiring Two Switches Together
Figure 4-9. MERLIN LEGEND to MERLIN LEGEND T1 Tie Direct
Connection on the same continuous property
DS
1
Interface
MERLIN
LEGEND
D8WD8W
MERLIN
LEGEND
Cross Connect Field
DS
1
Interface
W/BL(T)
BL/W(R)
W/O(T1)
O/W(R1)
W/BL(T)
BL/W(R)
W/O(T1)
O/W(R1)
