Lucent Technologies MERLIN LEGEND Release 6.1 Installation

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-10
Connecting a Printer to the Control Unit
Figure 5-3. Connecting a CAT and Printer on the Same AC Outlet
Connecting a CAT and Printer on a Different
AC Outlet
If the printer is not grounded to the same AC outlet as the control unit or
CAT, or if the printer is more than 50 ft. (15.2 m) from the control unit,
use the following procedure to connect a CAT serial printer to the control
unit.
Processor
CAT PLUS Connections
Using Same AC Outlet
Z200A
EMI
Filter
355A
SMDR Port
Short Cord
Long Cord
CAT Printer
D8W-87
CAT PLUS Terminal
