Introduction
Page 1-1
Installation Sequence
MERLIN LEGEND Communications System Release 6.1
Installation
Issue 1
August 1998
MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
1
Introduction 1
Installation of the MERLIN LEGEND Communications System involves
the following:
■ Installing the control unit
■ Installing the telephones
■ Connecting system wiring
■ Installing optional equipment
This chapter provides an overview of the installation process, which
varies from customer to customer.
Installation Sequence
The following is a list of the components that the system can include and
shows the order in which you should install them. When installing your
customer’s system, try to adhere to this order as much as possible:
1. Install the control unit (required).
2. Connect power accessories to the control unit (optional).
3. Install the telephones (required) and adjuncts (optional).
4. Connect the telephones to the control unit (required).
