MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Connecting Data Equipment
Page 6-7
Analog Voice and Modem Data Stations
Figure 6-1. Analog Voice and Modem Data Equipment Configuration
Processor
TURN OFF
POWER BEFORE
INSERTING OR
REMOVING
MODULES
CAUTION
408, 408 GS/LS,
or 008 Module
D8W cord
STATION
EVEN ODD
BR-241-B1
Bridging Adapter
D8W cord
LINE jack
Analog Multiline
Telephone
D8AC cord
GPA
Modem
VT jack
TEL/EQUIP jack
LINE jack
D4BU
cord
SERIAL
connector
EIA-232-D Cable
Data Terminal
Two adjacent
Analog Extension jacks
TEL/OTHER
jack
AC Outlet
AC Outlet
