MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Connecting Data Equipment
Page 6-16
Terminal Adapter Data-Only Stations
Figure 6-5. Terminal Adapter Data-Only Equipment Configuration
Processor
TURN OFF
POWER BEFORE
INSERTING OR
REMOVING
MODULES
CAUTION
008 MLX or
408 GS/LS-MLX
Module
D8W cord
SERIAL
connector
EIA-232-D
Cable
Data
Terminal
MLX
Extension
jack
Terminal Adapter
PORT 1
POWER
WP90110-L7
Power Supply
AC Outlet
AC Outlet
LINE jack
440A4 (100 )
Terminating
Resistor Adapter
