MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-25
Connecting a Printer to the Control Unit
Applications Printer DIP Switch Settings
For the Applications Printer, the only DIP switch setting is the control
switch. Set all control switch DIP switches (1 through 8) to
off (open).
* Open = off; Closed = on
Table 5-3. Lucent Technologies Printer DIP Switch Settings
*
Switch 1 Switch 2 Control Switch
DIP 1-On DIP 1-On DIP 1-Off
DIP 2-On DIP 2-On DIP 2-Off
DIP 3-On DIP 3-Off DIP 3-Off
DIP 4-On DIP 4-Off DIP 4-Off
DIP 5-On DIP 5-On DIP 5-On
DIP 6-On DIP 6-On DIP 6-Off
DIP 7-On DIP 7-On DIP 7-On
DIP 8-On DIP 8-Off DIP 8-Off
