Page #71 background imageLoading...
Page #71 background image
MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the Control Unit
Page 2-6
AC Power and Grounding
AC Power and Grounding
Proper power and grounding are essential for the system to run correctly
and safely.
!
CAUTION:
If any of the following requirements are not met, the
customer must contact a licensed electrician. Do not install
the system until all requirements are met.
Verify that all of the following power and grounding requirements are
met:
The load center of appropriate current rating must be equipped
with circuit breaker(s) labeled
120 V AC, 15 amps.
Each breaker must protect one dedicated quad AC outlet or two
dedicated duplex AC outlets.
All AC outlets must connect to the same load center and the
ground wire must connect to the single-point ground bar on the
first AC outlet (see Figure 2–1).
One outlet must have an attached ground bar connected by a #6
AWG copper wire to an approved ground (see “Approved
Grounds,” later in this chapter, for a description of approved
grounds). This ground bar is the system’s single-point ground (see
Figure 2–1).
To prevent someone from accidentally shutting off the power,
do
not
connect the control unit to a switch-controlled outlet.
The AC outlet should be within 5 ft. (152 cm) of the control unit.
Each carrier requires one AC outlet receptacle.
Auxiliary equipment requires additional AC outlets.
If a printer or PC is installed on the system, it must be plugged into
the same AC branch as the power supply of the basic carrier.
