Lucent Technologies MERLIN LEGEND Release 6.1 Installation

MERLIN LEGEND Communications System Release 6.1
Installation
555-661-140
Issue 1
August 1998
Installing the PC, CAT, or Printer
Page 5-11
Connecting a Printer to the Control Unit
NOTE:
If you are installing the printer in a different room than the control
unit, make sure that both locations have working wall outlets and
wall jacks, and that the building wiring has been connected so that
the wall jacks in each location connect with each other.
You need the following hardware for the following procedure:
■ 248B adapters
■ 355AF, 355A adapters
■ 400B2 power adapters
■ D8W cords
■ D6AP power cords
■ D8AM modular crossover cable
■ M7U null modem cable (25-pin cable)
■ Z3A2, Z3A4 ADUs
■ 2012D transformer
■ Z200A EMI filter
To connect a CAT printer on a different AC outlet, first make the
connections at the control unit, then at the printer.
Follow the steps below to make the connections at the control unit.
Refer to Figure 5–4 throughout the procedure.
!Plug the short end of a Z200A EMI cord into the SMDR jack on the
control unit.
!Plug the other end of the Z200A EMI cord into a 355AF adapter.
!Plug the 355AF into one end of an M7U null modem cable.
!Plug the other end of the M7U null modem cable into the 25-pin
female connector on a Z3A4 ADU.
