Connecting the Control Unit to the Network Interface
Page 4-5
Wiring
RJ21X Interface
The RJ21X network interface has a female 50-pin (25-pair) amphenol
connector, as shown in Figure 4-1 on page 4-6
.
To connect the RJ21X interface to the control unit, you must build a
wiring field between the RJ21X interface and the control unit using a
66-type block (RJ21). This field converts the female amphenol
connector to sets of four 1-pair modular jacks.
