3-43
[10] SWING PARKING BRAKE RELEASE SWITCH
This switch makes it possible to perform swing operations for a short time, even when there is a
problem in the swing parking brake electric system. Do not use this switch except in
emergencies. Repair the problem as soon as possible.
This switch (10) is used to make it possible to carry out operation
temporarily if any problem should occur in the swing parking brake
system (when the display shows “E03”).
• (a) FREE position: When abnormal (move switch up)
• (b) NORMAL position: When normal (move switch down)
• If the display shows “E03”, move the switch up to the FREE
position, to make it possible to carry out work.
• When pushing this switch up to the FREE position, the swing
lock monitor being to flash.
