3-50
[5] ACCELERATOR PEDAL
The accelerator pedal should only be used to control the crane operation while the machine is
stationed.
During traveling operation, use of this pedal is strictly prohibited; otherwise it may cause an
accident due to an operation error which may lead to serious personal injury.
During traveling operation, always adjust the engine speed only by turning the fuel control dial.
This pedal (6) is used to adjust the engine speed or power during
the crane operation.
• (a) Low idling: Release your foot from the pedal.
• (b) Full throttle: Press the pedal fully.
The engine speed is set by the fuel control dial and the value is
given a priority; thus the speed will not be slower than the value
even when your foot is released from the pedal.
For the accelerator pedal control, use the fuel control dial to set
the minimum engine speed required, in advance.
