IMPULSE•VG+ Series 3 Instruction Manual – 07/25/05
5-66
39 External OH2 External Overheat Alarm
3A Trm A2/A3 Enable Analog Inputs A2 and A3 are
Enabled
3D Fref UP Cmd Used with B4-01
3E Fref Down Cmd Used with B4-01
3F Fault Reset Fault Reset; Normally Open
40 Fast Stop N.O. Decel to Stop by B5-08 n/a
41 Motor 2 Switch Motor 2 enabled 5-55
42 Fast Stop N.C. Decel to Stop by B5-08 5-5
43 Timer Enable Closed: enable ON-Delay/OFF
delay timer
5-40
45 + Speed Cmd Trim Control Increase
46 — Speed Cmd Trim Control Decrease
47 Analog Hold Analog Frequency Reference
Hold
4C DCInj Activate DC Injection Brake
50 Ext Spd Search 3 Micro-Speed Gain 1 and Load
Float extent.
53 Comm Test Comm Loopback Test
55 Drive Enable On = Inverter Ready
56 Klixon N.O. Klixon Input; Normally Open
57 Klixon N.C. Klixon Input; Normally Closed
58 Brake Answer back Brake Answer Back
59 Alt F-Ref Up Lmt Alternate Fre Ref Up Limit
5A Maintenance Reset Reset Maintenance Timer 5-41
5B BE6 Up Speed Lmt Limit Fref to C8-17
5C Weight Measure Measure by C10-01 5-35
5D Load Float Ext AMS C8-15 Time to C8-10
5E M-Spd Gni + LF-E Micro Speed Gain and Load
Float Extend
5F Phantom Fault N.C. Stop by C3-09
60 Index Enable Enables index 5-43
61 Brake Test See C8-19 5-31
62 Weight Limit N.O. Upper Limit Stop; Normally
Open
63 Phantom Fault N.O. Stop by C3-09
64 PG Ch1 Output Switches PG output to Ch 1
65 Dwell Enable Enables Dwell function 5-50
66 Load Share Enables Load Share function 5-22
* Initial value is determined by X-Press Programming (Table 4.1 to 4.2).
Parameter
Code Display Function
Ref Page
Number
