102
Mahr GmbH • Digimar 817 CLM
5 - End of program with
Stop after last step / workpiece
– Once the last workpiece in the program run has
been measured appears the following question:
Cancel or Continue with the next workpiece.
Continue
– After a workpiece has been completely measured,
the next workpiece will be inspected. In this case
the program run can be aborted.
1. After last step
2. Continue...............
6 - Upper control limit / lower control limit factors
To avoid having to look at all control charts after having
completed the measurement of a sample, the height
measuring instrument can output warnings in order to
draw the operator’s attention to certain control charts.
The warning limits result from the multiplication of the
control limits with the entered factor.
Example: With a factor of 0.9 a warning is issued if a
mean or range value reaches 90% of the control limit
value.
UCL-LCL factor:
____1.000________
7 - Reference point position
This function is only required if you work with both
coordinate transformation and automatic positioning. At
this point, enter the origin of the workpiece coordinate
system relative to the base plate in both Z and X. With
learn programming, these values are entered
automatically.
Ref. point position
____1.000______ Z
Ref. point position
____1.000______ X
8 - Enter workpiece / part number
YES
The operator can assign a number to each workpiece.
This number is saved with the name of the measuring
program. When starting a measuring program, the
operator can accept the displayed part number or enter
a new one.
Advantage: the operator can search for a certain part
number when evaluating data or for measuring records
with individual measuring values. It is also possible to
assign the same number to several workpieces.
NO
The part number that is displayed after the start of
a measuring program is increased by 1 after each
measurement.
