10.4.1 Correction factors in the Z-axis
The accuracy values specified for the Mahr height
measuring instruments are only achieved with
standard probing elements and the Mahr correction
factor table.
Please refer to chapter 6.14.6.3.
Settings
Die-down time = 1.0
Contacting speed = 8 mm/s
10.4 Customer calibration
MENU
13. Data and printer
14. Advanced settings
5. Enter password
6. Correction tables
7. Clear functions menu
2. Factory - corrections
3. Customer- corrections*
4. MK height correction
Customer- corrections
Corr. Z-axis only
Corr. Perpend. only
Perpend. + Z-axis .
Confirm
ON
OFF
Before new correction values are determined, the
existing Z-values must be deleted.
6. Correction tables
7. Clear functions menu
8. Import language from USB
4. Delete all data files
5. Delete customer corrections
6. Delete production data tables
With „YES“ the values in the customer correction table
will be deleted!
Return to „Measuring menu“
CE
2x
Delete all
CE
Start
