Mahr Digimar 817 CLM - Initialization of the Internal Memory

131
Mahr GmbH • Digimar 817 CLM
Description / Sequence Symbols / Pictures
When Programming Done and INIT RAM appears in the display, the
data transfer was successful
– After the data transfer the height measuring instrument must be
rebooted, following requests will appear in the display.
Language– Unit– Resolution– Time– Date
– Close the Eprom-Update-Software and remove the 0-modem
cable.
Close window
10.2 Initialization of the internal memory
Attention!!
When initializing all parameters are set to there initial state. All data,
such as programs, defined parameters or up-to-date measured
characteristics are deleted.
Programs in the USB memory are not deleted.
See point 6.14.7.2 Standard parameter
Secure regularly your data on an external storage medium!
– Shut down the height measuring instrument
Switch the height measuring instrument off and back on again
using the mains switch
– Press the ON/OFF key
The start up phase (booting up) appears in the display – wait until
the Mahr symbol appears
and immediately
– Press and briefly hold the CE- key
In the display appears the following message „Delete all data“.
The initialization starts and all parameters are in their original
status.
The following requests will appear in the display
Language– Unit– Resolution– Time– Date
CE
ON
OFF
Procedure
