6.14.6.2 Factory correction table
The pre-programmed factory correction factor is used
by the height measuring instrument. Usually, this
correction table is selected automatically if a height
measuring instrument is connected to channel 1.
The operator cannot adjust the factory correction
factor!
6.14.6.3 Customer specified correction table
A correction table that has been created by the
operator i.e. the customer for a specific measuring
instrument is selected. If a customer-specific correction
table is used, this is displayed in the basic state with
the message „CORRECTION“.
The star indicates the operator correction factor is
active.
6.14.6.4 Create a new correction table Z
Please refer to chapter 10.4 Customer calibration
6.14.6.5 Print a correction table
The actual operator correction table will be printed.
Please refer to chapter 10.4 Customer calibration
1. <-_______
2. Factory - corrections *
3. Customer corrections
4. MK height correction
5. Print correction tab
6. Perpend. correction
7. Reserved
8. Embedded service tests
Factory - corrections
Corr. Z-axis only
Corr. Perpend. only
Perpend. + Z-axis
1. <-_______
2. Factory - corrections
3. Customer corrections *
4. MK height correction
5. Print correction tab
6. Perpend. correction
7. Reserved
8. Embedded service tests
Customer- corrections
Corr. Z-axis only
Corr. Perpend. only
Perpend. + Z-axis .
1. <-_______
2. Factory - corrections
3. Customer corrections *
4. MK height correction
5. Print correction tab
6. Perpend. correction
7. Reserved
8. Embedded service tests
1. <-_______
2. Factory - corrections
3. Customer corrections *
4. MK height correction
5. Print correction tab
6. Perpend. correction
7. Reserved
8. Embedded service tests
