6.13.5 DATA Parameter RS232 OUT
By transmission of the data and/or measured values
the operator can choice whether to only send the
following:
- Coordinate (center)
- Diameter
- Coordinate center and diameter
to a printer or via the RS232 interface
6.13.6 Administer the USB memory
1. Center only
2. Diameter only
3. Center + Diameter
ACTUPART actual measured values – only actual
measured values
ALLPARTS all values – all measured values will be
attached to previous measured values
CORRECT Work correction table, only for info
EXPORT File - data that were exported
PRG1 Designation of a measuring program
Attention
USB - Format memory – all data in the memory will be
deleted.
EXPORT .TXT 12 09:33 28/08 2006
CORRECT . 0 09:33 28/08/2006
ACTUPART .TXT 2200 10:15 28/08/2006
ALLPARTS .TXT 1440 10:15 28/08/2006
PRG1 .PRG 1365 10:15 28/08/2006
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
1. <-_______
2. Folder USB memory
3. Format USB memory
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
1. <-_______
2. Folder USB memory
3. Format USB memory
Are you sure?
1. Yes
2. No
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
