Mahr Digimar 817 CLM - Measuring Bore Diameter and Center; Measuring Shaft Diameter and Center

50
Mahr GmbH • Digimar 817 CLM
3
4
1
2
QUICK
MODE
1
2
3
4
1
2
Basic measuring functions
1
3
Measuring tasks Measuring procedure Results as shown
in the display
Function Quick-Mode Speed keys
key
4.3.5
Determine the center of
a bore and the diameter
of the bore
4.3.6
Determine the center of
a shaft and the diameter
of the shaft
4.3.7
Contact from below to
determine the reversal
point (maximum)
only available when
Quick-Mode settings
is set to automatic
recognition of
plane / bore
