6.13.3.7 Color printer Yes / No
6.13.3.8 Printer specification
Indicates which USB printer has been connected.
Once the printer is connected to the USB interface, the
printer specification will appear briefly in the display.
6.13.4 Interface - RS232 OUT
The transfer parameters of the RS232 interface are as
follows:
Opto RS232 Duplex
Opto RS232 Duplex has a baud rate (transfer speed)
of 4800 Bits and set parity of 7 Bits.
Data format:
1234.5678_mm<CR>
1. <-_______
2. Printout results
3. Change record head data
4. Change record head form
5. Printer page length
6. Change customer-specific headline
7. Color printer Yes/No
8. Printer specification
1. Black/white printer
2. Color printer
1. <-_______
2. Printout results
3. Change record head data
4. Change record head form
5. Printer page length
6. Change customer-specific headline
7. Color printer Yes/No
8. Printer specification
HP
Deskjet 5700
MY49M1X13V046W
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
1. Opto RS parameter
2. User defined param.
