110
Mahr GmbH • Digimar 817 CLM
Select with: ÏÐ
2. Contact above 114.550
7.9.2 Data file directory
If more than 5 files have been saved, use the arrow
keys to display the names of the other files.
In addition to the file names, the following information
is also displayed: time and date that the file was saved
and the size of the file
The bottom row shows: the number of memory
locations occupied by measuring values (readings),
data blocks and files. Every free data block can hold
100 measuring values.
Display readings
PRG1 09:57 04/Sep/06 755
TEST1 09:59 04/Sep/06 1175
TEST5 10:18 04/Sep/06 587
248/8083 read. 3/80 blocks 3/40 files
Display readings
PRG1 09:57 04/Sep/06 755
TEST1 09:59 04/Sep/06 1175
TEST5 10:18 04/Sep/06 587
248/8083 read. 3/80 blocks 3/40 files
Select the appropriate characteristic by using the
cursor keys.
Data set n 2 Tue 4 2006
Result 45.0231 16:05
Part O.K.
Program step: 2
Sample n
o
.1
Testpiece n
o
.1
Nom. value 114.550
0.1000 -0.1000
7.9 Data administration
A measured value data file contains all the measured
actual values of a characteristic within a program.
1. <-_______
2. Learn programming (teach - in)
3. Create new program
4. Change existing program
5. Print out current program
6. UCL / LCL computation (measured values)
7. UCL / LCL computation (tolerances)
8. Menu program file management
9. Menu data file management
10.Program START
1. <-_______
2. File directory
3. Display contents of data file
4. Print out data file
5. Delete data file
6. Rename data file
7. Change data in data file
8. Export data file as ASCII file
7.9.3 Display contents of data file
All measured data can be displayed in tabular form
with the parameters saved along with the measuring
values. Select a program in the data file directory; use
the cursor keys to select a particular characteristic out
of the chosen program.
1. <-_______
2. Data directory
3. Display readings
4. Print readings
5. Delete file
6. Rename file
7. Change file
8. Data directory
1. <-_______
2. File directory
3. Display contents of data file
4. Print out data file
5. Delete data file
6. Rename data file
7. Change data in data file
8. Export data file as ASCII file
