Mahr GmbH • Digimar 817 CLM
6.13 Data and printer
6.13.2 DATA automatic transmit ON / OFF
The operator can chose to transfer the data and/or the
measured values between:
Manual Data transmission, once the „DATA key“
has been pressed
Automatic automatic data transmission after each
value has been measured
6.13.3 USB printer menu
6.13.3.2 Print results
– Refer to chapter 5.3
6.13.3.3 Changing record head data
Enter the appropriate text. Above every line to be
entered, you will find the text of the record head form.
Every line may contain up to max. 28 characters (the
consecutive numbering of the lines are not printed).
With the cursor keys, you can switch between
the lines with even numbers (2, 4, 6, 8 etc.) and alter
them accordingly.
1. <-_______
2. Standstill-time
3. Contacting speed
4. Resolution
5. mm/inch
6. Language
7. Date and time
8. LCD settings
9. Beep ON/OFF
10. Auto – off time (min)
11. Quick-Mode
12. Perpendicularity
13. Data and printer
14. Advanced settings
DIGIMAR 817 CLM V1.24 10:48:58 Wed 04 Apr 2007
Operator name : John Brown
Order number : 300.400.500
Description : Base plate
Ident. number : 4.123.456
If a statistics printer, e.g. MSP 2 is being used
which can only manage 24 characters a line, the
record head cannot be printed!
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
1. <-_______
2. 2. Printout results
3. Change record head data
4. Change record head form
5. Printer page length
6. Change customer-specific headline
7. Color printer Yes/No
8. Printer specification
1. Yes
2. No
3. Print part memory
Example of a record head data, the time and date
are automatically printed!
1. <-_______
2. Printout results
3. Change record head data
4. Change record head form
5. Printer page length
6. Change customer-specific headline
7. Color printer Yes/No
8. Printer specification
1 > Operator name :
2 > John Brown
3 > Order number :
4 > 300.400.500
5 > Description :
6 > Base plate
7 > Ident. number :
8 > 111.222.333
--------------------------------------------
1. <-_______
2. DATA auto-transmit on/off
3. USB printer menu
4. Interface parameters RS 232 Out
5. Transmission content RS 232 Out
6. USB file system management
1. Send using DATA key
2. Send automatically
