Mahr Digimar 817 CLM User Manual

21
Mahr GmbH • Digimar 817 CLM
1.3.5 Description of the symbols
1.3.5.1 Keypad symbols
Contacting a plane / surface from above
Measuring a groove
Measuring a bore
Contacting a shaft from above
Contacting a bore from above
Determining the center of a bore /
displaying the position
Perpendicularity
2D-selection key
Zero point
Select data for transmission
ON / OFF / Confirm
Statistics function
2D
0
DATA
Contacting a plane / surface from below
Measuring a bar
Measuring a shaft
Contacting a shaft from below
Contacting a bore from below
Min-Max function
Measuring a taper / angle
Calibrating a probe
Delete / Return to last value
Menu settings
Measuring program functions
Display the list of measured values
ON / OFF
ON
OFF
STAT
CE
MENU
PROG
DISP
