Mahr Digimar 817 CLM User Manual

22
Mahr GmbH • Digimar 817 CLM
Calculate distance
Auto
Automatic zero point 01, last measured
value
Relative value
Stop / Accept
Repeat/ Continue
Delete last characteristic
Calibrate twin probe
Calibrate probe / groove
Calibrate ledge from below
Vertically contact a ledge
Select horizontal probe
Travel upwards
Contacting a bar from above
1.3.5.2 Symbols - function keys
Calculating the symmetry between
2 planes
Automatic calculation of the distance
Zero point, last measured value
Absolute value
Pause
Cancel
Delete all characteristics
Inferior calibrated value
Calibrate the probe / ledge
Calibrate ledge from above
Horizontally contact a ledge
Select vertical probe
Travel downwards
Contacting a shaft from above
AUTO
AUTO
01
REL
AUTO
0,00
ABS
?
