113
Mahr GmbH • Digimar 817 CLM
7.9.8 Export data file (ASCII)
Select the amount of data to be sent / exported.
Measured values / measured value files can be
exported in various ways. In principle, the data is
always sent in ASCII format via the RS232 interface.
The sending of data via the internal USB memory is
further explained in chapter „5.2 Save measured
values“ and „5.3 Print measured values“.
1. <-_______
2. Readings
3. Readings + chara. n
o
4. Complete databank
5. Readings + tolerances
6. Readings: 1 row/part
7. Excel format Yes/No
1. <-_______
2. File directory
3. Display contents of data file
4. Print out data file
5. Delete data file
6. Rename data file
7. Change data in data file
8. Export data file as ASCII file
2. Only measured values 3. Measured values and
characteristic number
4. Databank of the measured values
6. Measured values; row/part5. Measured values with the tolerances
7. Excel Format YES/NO
Start Excel.
Open the data file in Excel and convert text using the
(text import wizard) function.
When in the Excel format the column seperation is
through a „semi colon“.
When not in the Excel format the column seperation is
through a „comma“.
