Mahr GmbH • Digimar 817 CLM
Universal probe set CXt2 consists of: 7034000
Carrying case 3015925
Probe carrier 3015917
Dimension Shaft length
Measuring crook d = 0.5 mm (.0197 inch) l = 78 mm (3.0708 inch) 3015918
Pin probe/-tip: ød = 1.2 mm (.0472 inch) l = 75 mm (2.9527 inch) 3015919
ls = 15.5 mm (.6102 inch)
Taper probe ød = 0-7.5 mm (0-.2952 inch) 3015920
Spherical probe TC-ødk = 3 mm (.1181 inch) l = 24 mm (.9448 inch) 3022000
Spherical probe TC-ødk = 2 mm (.0787 inch) l = 24 mm (.9448 inch) 3022001
Spherical probe TC-ødk = 1 mm (.0393 inch) l = 24 mm (.9448 inch) 3022002
Extension M3 - M3 d = 4 mm (.1574 inch) l = 20 mm (.7874 inch) 3015921
Extension M3 - M2.5 d = 4 mm (.1574 inch) l = 20 mm (.7874 inch) 3015888
Software MarCom Standard 4102551
Software MarCom Professional 4102552
Data cable RS232 to connect to a PC 7024634
Adapter cable RS232-USB 4102333
Digital indicator MarCator 1086 4337020
12.5 mm / 0.001
Data connection cable Opto RS232 16EXr 4102410
Incremental probe P1514 H 4426810
Spare battery 4.8V 7000mAh NiMh 4862931
Mains power plug EURO FW 7555M/08 4102766
Adapter UK 1717618 9101328
Adapter US 1717715 4102778
MSP 2 Statistics printer 4102040
Data cable to 817 CLM 7024634
HP Ink-jet printer 5940 USB 4429015
USB cable 1.5 m (4.921 ft) 4883216
Accessories Set 817 t1 in a case 4429019
Consists of:
Probe M2 complete 4429256
Disc probe 4429226
Cylindrical probe 4429227
Taper probe 4429228
Spherical probe (depth) M2.5 / M2 4429221
Probe carrier 100 mm (3.9370 inch) 4429219
Probe carrier K4/30-K10/100 4429220
Styli K4/30 7023813
Styli K6/40 7023816
Styli K10/60 7023810
Styli K10/100 7023615
Accessories Set 817 t2 in a case 4429018
Consists of:
Probe M2 complete 4429256
Disc probe 4429226
Cylindrical probe 4429227
Taper probe 4429228
Spherical probe (depth) M2.5 / M2 4429221
Probe carrier 100 mm (3.9370 inch) 4429219
