16000 SERVICE/MAINTENANCE MANUAL BOOM
4
VIEW A
Switch
Opened
Item Description
1Boom Butt
2a Adjusting Rod – Boom only
2b Adjusting Rod – Boom with Luffing Jib
3Jam Nut
4 Coupling
5 Limit Switch
6 Cover
7 Spring Washer
8Spring
9 Spring Washer
10 Dowel Pin 6 mm (1/4 in) Diameter
11 Actuator Rod
12
Digital Level (see
Figure 4-3)
Roller
Over-Travel
7 8 9 10
11
2a or 2b
Stored
5
5
6
11
2a or 2b
4
3
Limit Switch Wiring
Receptacle
Switch
Terminals
Function
1 (green) 22 14 Max Angle
2 (black) 13 GND
3 (white) 21 12 VDC Supply
1
VIEW B
Switch
Closed
FIGURE 4-2
A10867
