16000 SERVICE/MAINTENANCE MANUAL POWER TRAIN
7
FIGURE 7-3
Item1 Description
1 Air Cleaner Assembly
1a Service Cover
1b Latch (8)
1c Primary Filter (2)
1d Secondary Filter (2)
1e Housing
2 Steel Tube
3Clamp (4)
4 Straight Adapter Fitting
5 Rubber Elbow Reducer
6Engine Intake
7 Mounting Lugs (4)
8 Service Indicator
8a Service Window
8b Reset Button
9 Decal With Service Instructions
1c
1d
Removal Tabs
1e
1c
1d
Removal Tabs
1e
IMG 7153
IMG 7152
8a
8b
1c
1
1a
9
1b
5
3
4
7
1
6
3
2
3
