16000 SERVICE/MAINTENANCE MANUAL INTRODUCTION
1
Proportional
Relief Valve
Suction
Manifold
Variable Accessory
Pump 400 to 5,000
psi
(28 to 345 bar)
To Other MAX-ER
Systems
Three Bank Valve Manifold
Telescopic Beam Extend
HS-72
HS-70
HS-88
HS-89
HS-71
HS-73
Pressure Control
Pilot
4,500 psi
(310 bar)
M16-07
M16-08
HS-68
Proportional
Relief Valve
Suction
Manifold
Variable Accessory
Pump 400 to 5,000
psi
(28 to 345 bar)
To Other MAX-ER
Systems
Three Bank Valve Manifold
Telescopic Beam Retract
HS-72
HS-70
HS-88
HS-89
HS-71
HS-73
Pressure Control
Pilot
4,500 psi
(310 bar)
HS-68
FIGURE 1-52
