Manitowoc Published 05-03-17, Control # 228-03 2-3
16000 SERVICE/MAINTENANCE MANUAL HYDRAULIC SYSTEM
2
Item Description Item Description
1 Filters, Return 7a Shut-Off Valve Handle
2a Fill Plug (manual fill port) 7b Locking Pin
2b Power-Fill Coupling 8 Hydraulic Tank Drain Valve
3 Breather 9 Vacuum Switch
4a Shrader Air Valve 10 Suction Manifold
4b Coupler 11 Tube Nut Fitting
5 DEF System Hoses (Ref.) 12 Vent Cap for System Fill
6 Thermostatic Valve
FIGURE 2-1
11
P2251
4a
Under Pumps
9
10
M1001267
M1001268
3
2b
2a
4b
8
Right Side
Right Side
M1001346
Top of Tank
5
1
