SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-10
Published 06-24-16, Control # 241-01
CRANE ASSEMBLY WITH SELF-ERECT
Operating Controls
In order to assemble and disassemble the crane with the
self-erecting system, the engine must be running and crane
Setup mode must be selected and confirmed.
The jacking cylinders, boom butt cylinder, gantry cylinders,
hydraulic disconnect, rotating frame pins, and crawler pins
are controlled by switches on the jacking and setup remote
controls.
See Section 3 for identification and operation of all controls.
Pre-Start Checks
Make the following checks before starting the engine upon
arrival at the assembly site. See Section 3 for starting
instructions.
Engine
o Check for leaks
o Check fuel, oil, diesel exhaust fluid (DEF), and coolant
levels
o Repair or refill as required
Gear Boxes
o Check for leaks
o Check fluid levels
o Repair or refill as required
Hydraulic System
o Check for leaks
o Check level
o Repair or refill as required
o Make sure hydraulic shut-off valve is open
Table 4-2. Load Data
Table 4-3. Swing Limits
WARNING
Burn and Inhalation Hazards!
Avoid possible injury. The temperature of exhaust and
exhaust components for a Tier 4F engine can be higher
than other engines and can cause serious burns.
Avoid physical contact with the exhaust gases and the
exhaust system components. Exhaust gases are harmful
to your health.
Keep all flammable materials away from the exhaust
system to prevent fire.
If it is necessary to service the crane while the engine is
running, inhibit (turn off) SCR regeneration using the
switch in the cab to prevent a higher exhaust temperature.
Jack and Pedestal Load Data
Maximum load on jack 40 824 kg (90,000 lb)
Jack pad size 610 mm (24 in) diameter
Jack pad weight 27 kg (60 lb)
Maximum load on carbody
pedestals
54 432 kg (120,000 lb)
Carbody pedestal size 762 mm (30 in) diameter
Carbody pedestal
assembly weight
58 kg (128 lb)
Crane Without Counterweight and Carbody on Pedestals
Gantry Crawlers Boom Butt
Safe to Swing
Yes No
Down Both Off 3,7 m (12 ft)
X
1
1
Must remain in the shipping position (Figure 4-12).
Up or Down Both Off 12,2 m (40 ft)—two-piece 0° to 45°
X
2
2
Limit swing to 5° in either direction from the center when lifting the crawler.
Up or Down Both Off 12,2 m (40 ft)—two-piece above 45° X
Up One or Two On 12,2 m (40 ft)—two-piece at any Angle
X
2
Crane with Counterweight and Crawlers on Ground
Up or Down Both On 12,2 m (40 ft)—two-piece at any Angle X
