Manitowoc 2250 - Outline Dimensions; Standard Crane (Series 3 Counterweight Arrangement Shown)

Reference Only
Manitowoc Published 06-24-16, Control # 241-01 1-7
2250 OPERATOR MANUAL INTRODUCTION
1
OUTLINE DIMENSIONS
Standard Crane (series 3 counterweight arrangement shown)
(3 ft)
0,91 m
Rotation
Rotation
(35 ft 9 in)
10,89 m
(2 ft 7-1/2 in)
0,80 m
(17 ft 2 in)
5,23 m
(37 ft 2-1/2 in)
11,34 m
(16 ft 6 in)
5,03 m
(11 ft 11-1/2 in)
3,64 m
(8 ft)
(2 ft 5 in)
0,73 m
(15 ft 3 in)
4,65 m
(6 ft 6 in)
1,98 m
(30 ft 9 in)
9,37 m
(42 ft 4 in)
12,90 m
(23 ft 6 in)
7,16 m
(23 ft 9-1/2 in)
7,25 m
Tailswing
(11 ft 11 in)
3,63 m
(7 ft 10 in)
2,40 m
(4 ft 2 in)
1,27 m
Without Counterweights
(32 ft 9 in)
9,98 m
With 4 ft Crawlers
With 5 ft Crawlers (Optional)
(27 ft)
8,23 m
7,91 m
(5 ft)
1,52 m
(Optional)
(4 ft)
1,22 m
(10 in)
0,26 m
(23 ft)
7,01 m
(3 ft 8-1/2 in)
1,12 m
(25 ft 11-1/2 in)
FIGURE 1-6
2,44 m
