Manitowoc Published 06-24-16, Control # 241-01 4-17
2250 OPERATOR MANUAL SETUP AND INSTALLATION
Remove Adapter Frame and Carbody from
Trailer
NOTE: The circled numbers in Figure 4-10 correspond to
the numbers of the following steps.
1. Unlatch and open the doors covering the adapter frame
hydraulic disconnect (see View A).
2. Position the trailer carrying the adapter frame and
carbody under the rotating bed.
3. Use the alignment pendants hanging from the rear of the
rotating bed as a guide when positioning the trailer (see
View B). Observe the specified alignment tolerance.
4. Retract the jacks only enough for the alignment
pendants to be pinned.
5. Pin the front and rear alignment pendants to the adapter
frame (see Views C and D).
6. Slowly extend the jacks to lift the adapter frame and the
carbody to clear the trailer.
Alignment pendants will center the adapter frame and
carbody under the rotating bed.
CAUTION
Prevent Equipment Damage!
Avoid hitting the swing motor while backing the trailer. The
motor, piping, or hoses may be damaged.
