SETUP AND INSTALLATION 2250 OPERATOR MANUAL
4-64
Published 06-24-16, Control # 241-01
6. Repeat step 5 for the other side box.
7. Repeat step 1
through step 6 at the other end of the
carbody.
Removing Carbody Counterweights (Series 3)
See Figure 4-33 for the following procedure.
Remove the upper counterweight before removing the
carbody counterweights, as follows.
1. Using the assembly block and the 4-leg chain sling from
the 2250, attach the chain sling hooks from the
assembly block to the lifting lugs on the side box.
2. Remove the side box connecting pins (see View B).
3. Slowly lift the side box clear from the carbody and lower
it onto the ground or to a transport vehicle.
4. Repeat step 1
through step 3 for the other side box.
5. Attach the chain sling hooks from the assembly block to
the lifting lugs on the center box.
6. Remove the center box connecting pins (see View A).
7. Slowly lift the center box clear from the hooks on the
carbody and lower it onto the ground or to a transport
vehicle.
8. Repeat step 1
through step 7 for the other end of the
carbody.
