Manitowoc Published 06-24-16, Control # 241-01 4-61
2250 OPERATOR MANUAL SETUP AND INSTALLATION
4
FIGURE 4-33
View B
P814
Center Box
View A
P813
Side Box
Side Box
Carbody
Counterweights
Required
Weight Each
kg (lb)
Total Weight
kg (lb)
Series 2
2 Center Boxes 13 608
(30,000)
27 216
(60,000)
Series 3
2 Center Boxes
13 608
(30,000)
54 431
(120,000)
4 Side Boxes
6 804
(15,000)
Side Box
Lifting Lug
(4 places)
Center Box
Lifting Lug
(4 places)
Hook
Pin
(2 places)
Slot
Pin
(2 places)
