OPERATING CONTROLS AND PROCEDURES 2250 OPERATOR MANUAL
3-4
Published 06-24-16, Control # 241-01
SYMBOL IDENTIFICATION
The following symbols are used to identify controls on Manitowoc Cranes. Some symbols shown may not apply to your crane.
Safety Alert:
Warning/Caution
Operating Limit
System Fault
Engine Diagnostics
FIGURE 3-1
Air Conditioning
Air Conditioning Temperature
Battery Voltage
Blower (fan)
Boom (lower)
Boom (raise)
Crawler (travel)
Crawler (travel parked)
Crawler Travel Forward (left):
Arrow indicates which crawler
is operating and direction of
travel with drive motors to the
rear
Crawler Travel Forward (right):
Arrow indicates which crawler
is operating and direction of
travel with drive motors to the
rear
Crawler Travel Reverse (left):
Arrow indicates which crawler
is operating and direction of
travel with drive motors to the
rear
Crawler Travel Reverse (right):
Arrow indicates which crawler
is operating and direction of
travel with drive motors to the
rear
Contrast
Clam Closing Pressure
Air Pressure Gauge
