INTRODUCTION 2250 OPERATOR MANUAL
1-2
Published 06-24-16, Control # 241-01
IDENTIFICATION AND LOCATION OF COMPONENTS
Crane Components
A1048
19
2
4
5 (both ends)
1
18
21
22
9
13
12
14
11
3
77
15
16
6 (both ends)
810
20
17
Item Description
1 #44 Heavy Lift Boom
2Operator’s Cab
3 Boom Butt Handling Cylinder
4 Rotating Frame Adapter
5 Carbody Counterweight (both ends)
6 Step (both ends)
7 Jacking Cylinders (qty 4)
8 Carbody (undercarriage)
9 Crawler (both sides)
10 Rotating Bed
11 Upper Counterweight
12 Backhitch Gantry (telescopic)
13 Gantry
14 Boom Stop
15 Equalizer
16 Wire Rope Guide (boom butt)
17 Boom Straps
18 Wire Rope Guide (boom top)
19 Upper Boom Point
20 Lower Boom Point
21 Weight Ball
22 Load Block
23 Fixed Jib
24 Jib Stop
25 Jib Strut
26 Backstay Pendant
27 Jib Pendant
28 Jib Point
25
28
21
23
24
26
27
FIGURE 1-2
